VQ340 / 34" of Pure Visual Force.

WQHD, Curved Display, 2 slot Independent GPU, delivers exceptional visual and multitasking capabilities.
  • Stunning Visual
    34” WQHD Resolution and Curved Display
  • Independent 2 slot GPU
    Up to 120W, Max 250*137*37 mm
  • Dual Channel Memory
    Support 2 x SO-DIMM DDR5/DDR4 Max. 64GB
  • Extra Options
    1 x PBP HDMI In, 1 x PBP DP In
  • Versatile Button Functions
    LCD on/off, Menu, Key1, Key2, Auto Adjust
  • External Camera
    3MP/5MP/8MP Camera + Single/Dual Mic
  • Adjustable Stand
    Tilt, Swivel
  • Color
    Black / White

CPU/Memory Support

Drivers

BIOS

FAQ

Manual

User Guide
Model Name VQ340
Display 34 inch, WQHD (3440 x 1440) 21:9, 60Hz, VA, 1500R curvature radius, Wide-Angle View
Motherboard Support Standard 170 x 170 mm Thin Mini ITX Motherboard
(Intel H810/B760/Q670/B660/H610, Intel i7-13620H)
Processor - Intel Socket LGA1851 for Core Ultra CPU (Series 2) Ultra 9/ Ultra 7/Ultra 5 (Up to 65W TDP)
- Intel Socket LGA1700 for 14th / 13th / 12th Gen Intel Core i7/ i5/ i3, Penti-um Gold / Silver and Celeron CPU (Up to 65W TDP)
- Intel 13th Gen Intel Core i7/ i5/ i3 Mobile CPU (Up to 65W TDP)
Graphics Independent 2slot GPU up to 120W (250*137*37 mm )
*Only compatible with special H610 Thin Mini ITX Motherboard
Memory From Motherboard
Support 2 x SO-DIMM Max. 64GB DDR5
Support 2 x SO-DIMM Max. 64GB DDR4
Storage From Motherboard
1 x M.2 M Key 2280 NVMe SSD
Wireless Data Network M.2 Wi-Fi 7/6E/6/5 + Bluetooth 5.x
Camera External 3MP Camera + Single/Dual Mic
Optional : 5MP/8MP Camera + Single/Dual Mic
Back I/O Ports From Motherboard
1 x DC In (5.5/2.5 mm)
1 x HDMI Out
1 x VGA
2 x USB 3.2 Gen1 Type A (5Gbps)
1 x Realtek 1Gb Ethernet port
2 x USB 3.2 Gen2 Type A (10Gbps)
2 x Audio jacks
Side I/O Ports 2 x USB 2.0 Type A
Extra I/O 1 x PBP HDMI In (Optional)
1 x PBP DP in (Optional)
DVD N/A
Button Power Button, LCD on/off, Menu, Key1, Key2, Auto Adjust
Speaker 2 x 3W Speakers
Power 120W Adaptor
300W Adaptor for Independent GPU (Optional)
Security Kensington Lock
Stand Regular Stand
Tilt: -5°~20°
Swivel: -80°~80°
Accessories N/A
Color Black/White
